Electric Charging stations
As the paradigm of automobile industry is shifting from fossil fuels to non-fossil & renewable energy sources, demand of charging stations and E-vehicles is increasing multifold. Therefore, we are also fully equipped to supply complete solutions for charging stations & related infrastructure. We are offering highly customized solutions for various countries demands based on different KWs & protocols.
| Wattage | Current Type | Mount Type | Input Details | Output Details |
|---|---|---|---|---|
| 7kw | AC | Wall/Ground | 1-P-220V, 3-Wire | OP-1,220V 32A, IEC 61851-22, IEC 62196-2 Mode-3, Type-2 |
| 22kw | AC | Ground Mount | 3-P-5-Wire 380V | OP-1, 380V 3-P 16A IEC 61851-22, IEC 62196-2 Mode-3, Type-2 |
| 7kw | DC | Portable | 1-P 220V | OP-1 200-750VDC < 11A |
| 15kw | DC | Portable | 3-P 380V | OP-1 200-750VDC < 37.5A |
| 20kw | DC | Ground Mount | 3-P 380V | OP-1 200-750VDC < 50A |
| 30kw | DC | Portable | 3-P 380V | OP-1 200-750VDC < 40A |
| 40kw | DC | Portable | 3-P 380V | OP-1 200-750VDC < 40A |
| 30kw | DC | Ground | 3-P 380V | OP-1 Or 2 200-750VDC < 75A |
| 40kw | DC | Ground | 3-P 380V | OP-1 Or 2 200-750VDC < 75A |
| 50kw | DC | Ground | 3-P 380V | OP-1 Or 2 200-750VDC < 112A |
| 60kw | DC | Column | 3-P 380V | OP-1 Or 2 200-750VDC < 150A |
| 80kw | DC | Ground | 3-P 380V | OP-1 Or 2 200-750VDC < 107A |
| 90kw | DC | Column | 3-P 380V | OP-1 Or 2 200-750VDC < 107A |
| 120kw | DC | Ground | 3-P 380V | OP-1 Or 2 200-750VDC < 160A |
| 160kw | DC | Ground | 3-P 380V | OP-1 Or 2 200-750VDC < 250A |
| 142kw | 2*DC,1*AC | Ground | 3-P 380V | 3*Ops OP-1 DC CCS-2 < 60KW OP-2 DC CHAdeMO < 60 KW OP-3 AC 3P < 22KW |
